Description
UNI-T LM100 Laser Distance Meter adalah Alat ukur jarak atau dimensi ruang dengan rentang ukur sampai 100 Meter. Alat-alat ini dapat digunakan dalam desain interior/eksterior, konstruksi, pengawasan pabrik, inspeksi teknik, pengumpulan bukti kecelakaan lalu lintas, pengembangan real estat, penilaian kebakaran, dan banyak lagi.
 |
 |
Fitur UNI-T LM100
- Eksterior ergonomis, penanganan yang nyaman
- Rentang pengukuran: 0,05 – 100 m.
- Akurasi milimeter
- Layar HD besar dengan berbagai sudut
- Penyeimbang fisik dan elektronik
- indikasi audio; indikasi baterai rendah.
- Beberapa fungsi: Pengukuran Maks/Min/terus menerus, perhitungan perpindahan, penyimpanan data, dan banyak lagi
- Mati otomatis setelah 3 menit tanpa operasi.
Spesifikasi UNI-T LM100
| Specifications | LM100 | Specifications | LM80 | LM100 | LM120 | LM150 | ||||||
| Display type | LCD | Display type | LCD | |||||||||
| Display size | 2.0-inches | Display size | 2.0-inches | |||||||||
| Range | 100m | Range | 80m | 100m | 120m | 150m | ||||||
| Min. display unit | 0.001m | Min. display unit | 0.001m | |||||||||
| Measurement units | m/ft/in | Measurement units | m/ft/in | |||||||||
| Measurement basis | front/rear | Measurement basis | front/rear | |||||||||
| Accuracy | ±(2mm+5 x 10-5 D) | Accuracy | ±(2mm+5 x 10-5 D) | |||||||||
| Laser class | 2 | Laser class | 2 | |||||||||
| Laser type | 630~670nm, ﹤1mW | Laser type | 630~670nm, ﹤1mW | |||||||||
| Features | Features | |||||||||||
| Single measurement | √ | Single measurement | √ | |||||||||
| Continuous measurement | √ | Continuous measurement | √ | |||||||||
| Max/Min/Area | √ | Max/Min/Area | √ | |||||||||
| Volume | √ | Volume | √ | |||||||||
| Pythagoras | √ | Pythagoras | √ | |||||||||
| Add/Subtract | √ | Add/Subtract | √ | |||||||||
| Auto leveling horizontal | √ | Auto leveling horizontal | √ | |||||||||
| Auto leveling vertical | √ | Auto leveling vertical | √ | |||||||||
| Data storage | 20 groups | Data storage | 20 groups | |||||||||
| Auto power off | 3 minutes without operation | Auto power off | 3 minutes without operation | |||||||||
| Auto laser off | 30s without operation | Auto laser off | 30s without operation | |||||||||
| Auto backlight off | 10s without operation | Auto backlight off | 10s without operation | |||||||||
| Tilt angle | ±90.0° | Tilt angle | ±90.0° | |||||||||
| Audio indication | √ | Audio indication | √ | |||||||||
| Battery status display | √ | Battery status display | √ | |||||||||
| Storage temperature |  -20℃~70℃ | Storage temperature |  -20℃~70℃ | |||||||||
| Operating temperature | 0℃~40℃ | Operating temperature | 0℃~40℃ | |||||||||
UNI-T LM100 Laser Distance Meter >>>>> Spec sheet (PDF)
